HANWHA Manifold Multi Tube Valve J1301695 HP09-900049
Specifications:
HANWHA Manifold Multi Tube Valve J1301695 HP09-900049
1 HP06-000457 FITTING 1
2 HP06-900089 STRAIGHT_FITTING 2
3 HP09-000127 MANIFOLD 1
4 HP13-000037A TUBE,PNEUMATIC 1
5 J1301070 STRAIGHT_CONNETOR_FITTING 6
6 HP14-002040 VALVE,SOLENOID 1
7 HP09-000129 MANIFOLD-HEAD_AIR_MODULE 1
8 HP06-000074 FITTING-STRAIGHT 10
9 HP06-900059 BOB ELBOW FITTING 10
10 HP04-900036 SUCTION_FILTER 10
1 FC09-001648A BRACKET-CABLE FIXER 1
2 PM02-000794A CUSHION-CABLE X 2
3 FC09-001481B BRACKET-CUSHION X 2 FC09-001481A
4 FC09-001577B BRACKET-FLAT_CABLE_CLAMP 1
5 FC09-001662B BRACKET-BKT CABLE X 2 FC09-001662A
6 PM02-000795A CUSHION-CABLE Y 2
7 FC09-001485A BRACKET-CUSHION Y 2
8 FC15-000971A COVER-COVER CHAIN Y 1
9 FC09-001771B BRACKET-BKT CABLE CHAIN X 1 FC09-001771A
10 EP19-900114 LIMIT SENSOR 3
11 FC28-900369 GREASE NIPPLE 4
12 FC18-001477A GREASE_NIPPLE_NUT 4 J70541105A
13 HP06-900080 STRAIGHT_FITTING 4
14 MC13-900032 LM_GUIDE-X 2
15 J70541038A SENSOR_DOG_X 2
16 FC05-000148E BASE-HEAD 1 FC05-000148B/ FC05-000148D
17 FC29-001213A DOG-DOG CRASH 1
18 FC09-007486A BRACKET-SERVO CONNECTOR BKT A6 1 J70530690B / FC09-004585A
19 J70541008A SENSOR_DOG-Y 1
20 EP08-001066 MOTOR,SERVO 1 EP08-900157
21 FC29-001212B STOPPER-CRASH CUSHION 2 FC29-001212A
27 FC09-001671A BRACKET-BKT CABLE CHAIN Y 1
Keywords:
Hanwha SM481 Plus Pick and Place Machine, Hanwha SM482 Plus Pick and Place Machine, Hanwha SM471 Plus Pick and Place Machine, Hanwha Decan S2 Plus Pick and Place Machine, Hanwha SM481 Plus SMT Assembly Line, Hanwha SM482 Plus SMT Assembly Line, Hanwha SM471 Plus SMT Assembly Line, Hanwha Decan S2 SMT Assembly Line.
