HANWHA CPU BOARD CP40 Main Control Board J1201030
Specifications:
HANWHA CPU BOARD CP40 Main Control Board J1201030
1 EP08-003194A MOTOR,STEP-CONV SHUTTLE MOTOR+PULLEY 1 EP08-000204(Old No.: J71531009A) + J71531190A
3 MC05-000151 TIMING BELT 1
4 J70531402A SHUTTLE_HOME_SENSOR_BKT 1
5 EP19-900109 PHOTO SENSOR 1
6 MC13-900069 LM_GUIDE 2 J2101818
7 FC05-000084A BASE-PULLEY 1
8 MC03-900081 BEARING 2
9 J70531570A SHUTTLE_BELT_TENSION_BKT 1
10 J71531190A PULLEY 1
11 J70531392A SHUTTLE_PULLEY_SHAFT 1
12 FC18-903151 SPACER 1
13 MC03-900081 BEARING 2
14 FC09-000764A BRACKET-PULLEY_FIX 1
1 FC07-001630A BLOCK-BLOCK_SHUTTLE 1
2 FC09-003302A BRACKET-BELT_FIX 1
3 FC30-001630A PLATE-BELT_FIX 1
4 EP19-900108 PHOTO SENSOR 2
5 J71531018A ENTRY_PCB_GUIDE_1650 2
6 FC09-007126A BRACKET-CONV_ST_SENSOR_BKT2 2
7 AM03-021739A CABLE ASSY-PCB SENSOR 1
8 AM03-021962A CABLE ASSY-BELT MOTOR(BW2-1) 1
9 J70531038A MOTOR_BRACKET 2
10 MC19-001136A PULLEY-WORK_W_BELT 4
11 J70531505A 180RINK_MOVING_SIDE_BKT1 2
12 J70531506A 180RINK_MOVING_SIDE_BKT2 2
13 J70531072C CNT_PANEL_FRONT 2
14 AM03-021742A CABLE ASSY-PCB SENSOR 1
15 FC09-004598A BRACKET-SHUTTLE_STP 1
16 HP03-001008 CYLINDER-STOPPER 1
17 HP06-900010 ELBOW FITTING 1
18 HP06-900263 HOSE NIPPLE 1
19 MC05-900059 BELT_SHUTTLE_1650 2
20 J7053184A SQUARE NUT M4 10
21 J70531039A IDLER_SPACER_45 8
22 J72531001A IDLER_2 J72531001A 4
23 MC19-001112A SHAFT-S_IDLER_CONV 4
24 J70531032A ST_SENSOR_BRACKET_2 1
25 J70531033A ST_SENSOR_BRACKET_1 1
26 J70531036A NUT_HOUSING 1
27 J70531037B MOTOR-BRACKET-SHUTTLE 1
28 J70531038A MOTOR_BRACKET 2
29 J70531039A IDLER_SPACER 6
30 FC09-004598A BRACKET_SHUTTLE_STP 1
31 J70531044A WD_NUT_BEARING_STOPPER 1
