HANWHA Drive Board HDLB 140313 0155
Specifications:
HANWHA Drive Board HDLB 140313 0155
1 J71531028A CONV_REAR_FRAME 1
2 FC39-001985A FRAME-EXTEND_R_100 1
3 FC29-004184A GUIDE-PCB_EXTEND_R_100 1
4 FC18-001478A IDLER_SPACER_S 9 J7053047A
5 J7253007A IDLER 2 8
6 J7053009A IDLER-SHAFT-S2 9
7 J70531090A PLATE_LONG_IN 2
8 FC18-902741 SOCKET HEAD CAP SCREW M4*10 (NI/ZN) 12
9 J7053184A SQUARE NUT M4 5
10 J70531091A PLATE_LONG_OUT 2
11 J71531050B PCB_GUIDE_END_2 1
12 FC18-902728 SOCKET HEAD CAP SCREW M3*12 (NI/ZN) 12
13 J70531106A BRACKET_BELT_MOTOR_S 2
14 J90831439B_AS CABLE ASSY-CONV_BELT4_STEP_MOTOR 1 AM03-007405A / AM03-007405B
15 FC18-902843 SOCKET SET SCREW [M3*5 (BL/ZN)] 6
16 J7153111A TEP MOTOR PULLEY 3
17 FC18-902722 SOCKET HEAD CAP SCREW M3*8 (NI/ZN) 24
18 FC18-902745 SOCKET HEAD CAP SCREW M4*15 (NI/ZN) 14
19 FC18-903490 SPRING WASHER [M4 (BL/ZN)] 26
20 J7253006A IDLER 1 4
21 J7053770A IDLER SHAFT-M 3
22 J7053763A IDLER SPACER-M[J7053763A] 3
23 J71530400C CLAMP REAR FRAME 1
24 FC18-902719 SOCKET HEAD CAP SCREW M3*6 (NI/ZN) 4
25 J7153034A CLAMP SHAFT 2
26 MC06-900006 BALL_BUSH LMU5 4
27 FC18-001480A BUSH SPACER 2 J7153033A
28 FC18-901355 C-RING DIA11(HOLE) 2
29 FC18-900900 HEX NUT 2
30 FC01-000022A ADJUST SHAFT 22 J7153010B
31 FC29-004426A STOPPER 2 J7253008A
Keywords:
Hanwha SM481 Plus Pick and Place Machine, Hanwha SM482 Plus Pick and Place Machine, Hanwha SM471 Plus Pick and Place Machine, Hanwha Decan S2 Plus Pick and Place Machine, Hanwha SM481 Plus SMT Assembly Line, Hanwha SM482 Plus SMT Assembly Line, Hanwha SM471 Plus SMT Assembly Line, Hanwha Decan S2 SMT Assembly Line.
