HANWHA SM411 421 431 451 track SUB IF board J91741076A
Specifications:
HANWHA SM411 421 431 451 track SUB IF board J91741076A
1 PT03-002322A STICKER-FOOT_LOCK_NUT;STD 1
2 FC15-000983A COVER BOTTOM FR 2
3 FC15-001391A COVER BOTTOM RL 1 FC15-000986A
4 FC15-000985A COVER BOTTOM RR 1
5 J7051010D HOUSING-FOOT 4
6 AM03-011300A ASSY,ETC,IMS-FOOT 4
7 FC18-903496 SPRING WASHER 16
1 FC15-005199A COVER-HEAD TOP COVER UNIV;STD 1
2 AM03-018404B ASSY,BOARD-HEAD_IF_BD_ARM 1
3 FC09-001574B BRACKET-HEAD_BOARD_BRACKET 1 FC09-001574A
4 FC29-900610 HEX SUPPORT 8
5 AM03-005341B ASSY,BOARD-MOTOR IF BOARD VER1.1 1 AM03-005341A
6 FC09-001568A BRACKET-FLAT_CABLE_BKT 1
7 FC09-003535B BRACKET-HEAD_BKT_PANEL 1 FC09-001573A
8 FC29-900148 HANDLE BG-10 1
9 FC09-001575A BRACKET-HARNESS_PLATE 1
10 FC09-001690A BRACKET-HEAD_BKT_FIX 1
11 FC09-001576B MOTOR_IF_BOARD_BKT 2 FC09-001576A
12 AM03-022591A ASSY,HEAD-FITTING_SUB 1
13 FC28-900369 GREASE NIPPLE 5
14 HP06-900079 ELBOW_UNION_FEMALE 5
15 J71541016B HARNESS_SUPPORT 2
16 FC09-004659 BRACKET-3-NIPPLE 1
17 FC09-004665A 2-NIPPLE_BRACKET 1 J70541017A
18 FC30-000990A PLATE-IO_BOARD_SHEET 1
19 FC30-000991A PLATE-MOTOR_IF_BOARD_SHEET 1
20 FC18-902795 BUTTON_HEAD_CAP_SCREW M10*20 (NI/ZN) 1
Keywords:
Hanwha SM481 Plus Pick and Place Machine, Hanwha SM482 Plus Pick and Place Machine, Hanwha SM471 Plus Pick and Place Machine, Hanwha Decan S2 Plus Pick and Place Machine, Hanwha SM481 Plus SMT Assembly Line, Hanwha SM482 Plus SMT Assembly Line, Hanwha SM471 Plus SMT Assembly Line, Hanwha Decan S2 SMT Assembly Line.
