HANWHA SM471 SM481 Z Axis Nozzle Rod J6711180B

HANWHA SM471 SM481 Z Axis Nozzle Rod J6711180B

Specifications:

HANWHA SM471 SM481 Z Axis Nozzle Rod J6711180B

32 J71531271A PCB_GUIDE_END_2 1 S1

33 J7253008A STOPPER 2

34 J7153010B ADJUST SHAFT 2

35 J7153034A CLAMP SHAFT 2 S7

36 J7153033A BUSH SPACER 2

37 MC06-900006 BALL_BUSH 4

S1 FC18-902728 SOCKET HEAD CAP SCREW M3*12 (NI/ZN)

S2 FC18-902722 SOCKET HEAD CAP SCREW M3*8 (NI/ZN)

S3 FC18-902741 SOCKET HEAD CAP SCREW M4*10 (NI/ZN)

S4 FC18-901866 SOCKET HEAD CAP SCREW

S5 FC18-902740 SOCKET HEAD CAP SCREW M4*8 (NI/ZN)

S6 FC18-902733 SOCKET HEAD CAP SCREW M3*20 (NI/ZN)

S7 FC18-902719 SOCKET HEAD CAP SCREW M3*6 (NI/ZN)

NO. Lev. PART NO. PART NAME Q'TY Old No. Screw Reference

1 J70531076B BRACKET_BD_OUT_SENSOR 1 S1

2 EP19-900101 PHOTOELECTRIC_SENSOR 2 S2

3 J70531607A BD_OUT_SENSOR_GUIDE 2 S2

4 FC39-001987A FRAME-EXTEND_R_325 1

5 J7053047A IDLER_SPACER_S 9

6 J7253007A IDLER 2 8

7 J7053009A IDLER-SHAFT-S2 7

8 FC09-004555A BRACKET-STOPPER 2 S3

9 FC09-004556A BRACKET-SENSOR 3 S4, S5

10 HP03-000118 CYLINDER 2

11 HP06-900010 ELBOW FITTING 3

12 HP06-900263 HOSE NIPPLE 2

13 EP19-900099 PHOTO SENSOR 4 S5

EP19-001025 SENSOR,OPTIC 4 S5

14 J70531090A PLATE_LONG_IN 2 S1

15 J70531091A PLATE_LONG_OUT 2 S1

16 FC29-004141A GUIDE-PCB_EX_F_325 1 S5

17 J71531271A PCB_GUIDE_END_2 1 S5

18 1 S6

19 J7153111A STEP MOTOR PULLEY 3

20 J70531106A BRACKET_BELT_MOTOR_S 2 S7

21 J7053184A SQUARE NUT M4 7

22 J7253006A IDLER 1 4

23 J70531763A BRACKET_BELT_MOTOR_B 1 S7

24 J70531083A ALT_MOTOR_SUPPORT 4

25 1 S8

26 J70531761A PCB_GUIDE_FC_S 2 S9

27 J7053048A IDLER SPACER-M 3

28 J7053770A IDLER SHAFT-M 3

29 J70531764B STOPPER_CYLINDER_BKT 1 S6

30 J70531643A H30_STOPPER_BAR 1
