HANWHA SM471 SM481 power driver board Z-axis driver AM03-005372A
Specifications:
HANWHA SM471 SM481 power driver board Z-axis driver AM03-005372A
31 MC05-900048 TIMING BELT 1
32 MC11-000434A CAM 2
33 FC30-001164A PLATE-SENSOR_DOG 1
34 FC18-901347 E-RING 2
35 FC18-901044 HEX NUT [M3 (BL/ZN)] 2
36 FC18-902841 SOCKET SET SCREW [M3*4 (BL/ZN)] 2
37 FC18-902728 SOCKET HEAD CAP SCREW M3*12 (NI/ZN) 4
38 FC18-902719 SOCKET HEAD CAP SCREW M3*6 (NI/ZN) 6
39 FC18-902711 SOCKET HEAD CAP SCREW M2.5*8 (NI/ZN) 4
40 AM03-005553B CABLE ASSY-FLYING_CAMERA_IF 5 AM03-005553A
1 AM03-008031A CABLE ASSY-R1_MOTOR SM471_MD038 5
2 FC09-001513A FLY_SIDE_BRACKET 2
3 FC09-002294B BRACKET-MIRROR_SPRING_BRACKET 2 FC09-002294A
4 FC30-001147A PLATE-REF_PLATE 1
5 AM03-007591A ASSY,HEAD-SIDE_ILL_ASSY 2
7 FC30-000797A PLATE-INSULATION_PLATE 1
8 FC30-000798A PLATE-STEP_MOTOR_PLATE 1
10 EP19-900134 MICRO_PHOTO_SENSOR 1
11 FC09-001501A BRACKET-T_M_PULLEY_CLAMP 1
12 MC13-000268 LM GUIDE 1 MC13-000116
13 FC29-004278A PIN 1 J7155541A
14 FC09-001881A BRACKET-Z_CAP 1
15 HP06-900059 BOB ELBOW FITTING 1
16 FC29-001047C HOUSING-Z_ROD_HOUSING 1 FC29-001047B
17 FC09-001492B BRACKET-Z_BELT_CLAMP 1
18 MC05-000117 TIMING BELT 5 SPINDLE 2, 4, 6, 8, 10
MC05-000119 TIMING BELT 5 SPINDLE 1, 3, 5, 7, 9
19 FC09-001502B BRACKET-Z_IDLE_BODY 1
20 MC03-900127 BALL BEARING 2
21 J71551848A Z_IDLER_PULLEY 1
22 J70551874A Z_IDLE_SHAFT 1
23 HP07-000094A Y_PACKING 1
24 FC09-001490A BRACKET-LOCK_NUT_Z 1
25 FC18-001724A WASHER,WAVE-WAVE_WASHER 1 FC18-000960
26 MC03-900127 BALL BEARING 2
27 FC09-001489A BRACKET-Z_TOP_HOUSING 1
28 MC13-000124 SPLINE,BALL-BALL SPLINE 1
29 FC30-000927A PLATE-BEARING_P_PLATE;SPCC 1
30 FC09-001494A S_PULLEY_CLAMP 1
31 FC18-000967 SCREW-T_SPINDLE_SCREW 1
32 MC19-000339A PULLEY-SPINDLE_PULLEY 1
